X-808 HAS THE FOLLPWING SPEC

LCD Screen Function

1.Flash /on :Flash light mode .video function close.LED1 light (there into LED light)choose OFF can close LED1,adjust POWER can control the flash light output power .LCD screen flash output power will show 2.0-6.0 of the max output.

2. flash /OFF :video Mode,flash light close .choose LED1 will light a control lamp choose LED2 will light all lamps,then adjust POWER can control the LEDS light,LCD screen will show the LEDS number from 2.0-6.0/6.0 is the most lighting in the light.And choose OFF will close all of the lamps.

3 LED1/LED2/OFF/:LED mode choose menu

4,BUZZ/ON:Open Buzzer.BUZZ/OFF:Close buzzer

5 Prevent IR Choice:

M:Camera hot shoe flash .exterior trigger to flash that the flash function close .

S1: IR flash ,FM wireless flash ,exterior trigger flash .camera hot shoe close.

S2: Ready-flash.after others lights flash 2 times.it will lighting .IR flash.other flash will close.

S3: Continous flash function ,everytime can flash 5 times.power adjust close.all of flash open.

S4:Continous-flash .everytime can flash 15times.power adjust close,all of flash open.

6.Counter :when flash one more time that the counter will add a time.

Using way

1.Put it into the hot shoe jack of camera or insert to other equipment ,lock the fastness button,adjust you need the angle.
2.Fit the right batteries or put exterior power,Turn on the power switch,LCD screen will light,charge introduction sheet show, When finished charge the sheet will stop and introduction sheet will show,when finished charge the sheet will stop and buzzing .Modelling light(in the middle of LED)will light,The light will be stand by.
3.Deasil turn Power BUTTON,the light's power will increase .Anticlockwise it will reduce.
4.Press UP/DOWN BUTTON.the menu function will light,Continous to press it will light up or down rotative.Choose.you need thet press ENTER Button (OK) is fiished
5.Press the TEST Button that can do the manual test.

Reflect Flash :

Set the flash head faces to wall or celling ,that will make the bright reflect the subject,this can be soften the light on the subject and the shadow fade out.

The reflect bright may not work.if the wall and celling are too far away.The wall or celling is preferred to flat surface and whith color .There may some deviation color ,if the reflector surface is not white.
